Square Sheet Former with White Water Recovery and Auto-agitation

In pulp and paper laboratories, paper handmaking is one of routine work. This work involves many manual operations, needing much time and labor, and there is a potential of inter-operator variance handmade sheets. As a solution for these difficulties, we have developed this labor-saving machine. It automatically performs steps including opening/closing paper making tank, water feed, agitation, discharge and couching, thereby alleviating workload of the operator and enabling uniform sheet making.

Product Name	Square Sheet Former with White Water Recovery and Auto-agitation
Product Code	KRK-2558-II
Manufacturer	Kumagai Riki Kogyo Co., Ltd. ( KRK )
Availability from OpTest	Exclusive to Canada, USA, and Mexico

Specifications

Standard Specification the same as the sheet machine No.2558-1 with white water recovery and suction devices
Paper Making Size 250×250mm
Specimen Tank automatic opening/closing
Number of Agitation Operations selectable from 1to 9
Water Level in Specimen Water Tank automatic level setting with sensor
Number of Couching Operations 5 (1 to 9) by pre-setting counter
White Water Chest capacity 120L, material SUS-304, with agitator
Vacuum Tank SUS-304
Vacuum Degree max. 600mmHg
Vacuum Meter digital
Vacuum Pump 5 (1 to 9) by pre-setting counter
Power Source three-phase 200/220VAC 50/60Hz 10A
Air Source 0.5MPa
Outer Dimensions 2,210×890×2,250mm
Instrument Weight 980kg
