Square Sheet Former (250mm Square with Vacuum Tank)

Like the standard sheet machine, this machine rapidly makes specimen sheets for various property tests and processing aptitude tests. The paper making size is 25 cm square suitable for preparing specimens for diverse tests with less waste. It produces handmade sheets of uniform forming.

Product Name Square Sheet Former (250mm Square with Vacuum Tank)
Product Code KRK-2555-V
Manufacturer Kumagai Riki Kogyo Co., Ltd. ( KRK )
Availability from OpTest Exclusive to Canada, USA, and Mexico

Paper Making Size 250×250mm
Wire Cloth upper 150mesh or 80mesh lower 20mesh
Accessories couch roll, couch plate, agitator, drainage receiver
Optional mounting support
Outer Dimensions 1,200×850×1,380mm (with support)
Instrument Weight 123kg (with support)
93kg (without support)


Square sheet machine (with vacuum tank)
Vacuum Tank Capacity 40L, SUS-304
Vacuum Pressure max. 600mmHg
Power Source three phase 200/220VAC 50/60Hz 10A
Air Source 0.5MPa
Outer Dimensions 1200 x 850 x 1380mm
Instrument Weight 220kg



Request a Quote or Information
