Oken Type Smoothness and Air-permeability Tester (Digital Type)

This machine determines rupture stress by rapid tensioning. An impact is given to the specimen slackened to measure the energy loss at rupture. This test determines resistance of continuous paper against break on a rotary printing machine where a large tension may occur instantaneously. It also measures the dynamic strength of bags made of kraft paper in use. This tester is provided with a pendulum to measure the work of rupture of specimens. A test piece 15mm wide and 1800mm long is held with the gripper, and the pendulum is lifted to the specified position and released. The specimen is broken at a maximum tension, and the work in N∙m (kgf∙cm) is shown on the scale.

Product Name Oken Type Smoothness and Air Permeability Tester (Digital Type)
Product Code KRK-2040-C
Standards/Methods JIS P-8155-2010, JIS P-8117-2009, ISO 5636-6
Manufacturer Kumagai Riki Kogyo Co., Ltd. ( KRK )
Availability from OpTest Exclusive to Canada, USA, and Mexico

Measurement Area for Smoothness 8.08cm²
Measurement Load for Smoothness 8.08kg
Total Length of a Measurement Ring 733mm
Measurement Area for Air-permeability 645.16mm²(1.00in²)
Measurement range (switch of nozzles)
Median of Smoothness 100, 500, 1,000sec.
Median of Air Permeability 100, 500, 1,000, 2,000sec.
Electronic Manometer Capacity 1,000mmH2O
Standard Air Pressure 500mmH2O, adjustable in 3 stages
Timer display in three digits (sec.)
Power Source 100/110VAC 50/60Hz 1A
Air Source 0.5MPa
Outer Dimensions 340 x 420 x 410mm
Instrument Weight 40kg
