Bristow Tester (Pressurized)
Product Name : Bristow Tester (Pressurized)
Product Code :
Details : Measure the Liquid Penetration Behavior of Paper and Board
Standard and Methods :
Categories :Board including Packaging, Paper, Print Quality & Printability
Manufacturer : KRK (Kumagai Riki Kogyo Co. Ltd.)
Regional Availabilty : US/Can/Mex
Description
Normally, infiltration of liquid into paper is made at a certain pressure in the process of coating, printing, and bonding. This machine is developed in order to reproduce the desired conditions for this test. This new type of tester features a pressuring head box, instead of the normal pressure head box, to measure transfer of liquid through absorption by applying a certain pressure to the liquid.
Head Box 15mm wide, slit width 1mm
Contact Pressure 0.1 to 0.5MPa
Liquid Pressurization 0.003 to 0.01MPa (standard 0.005MPa)
Air Pressure in Service 0.5MPａ
Optional support (1,500mm disc)
Power Source 100/110VAC 50/60Hz 4A
Outer Dimensions 510×540×870mm
(in the case of 1,500mm option, the height is 1,500mm with a support)
Instrument Weight 102kg
